"Compact and Cost Effective" |
| |
- Innovative design, optimized for cost and performance, supports business-critical applications and cloud deployments
- Excellent RAS and outstanding uptime for an improved business environment
- Easy to deploy, integrate, service and manage
Outstanding uptime
With redundant hot-swap fans, disks and power supplies, the x3650 M4 provides a resilient architecture ideal for business-critical applications. Predictive Failure Analysis and light path diagnostics provide advanced warning on power supplies, fans, VRMs, disks, processors and memory. Redundant hot-swap components make it easy to replace failures without taking your system down.
|
|
PRODUCT FEATURES:
- Comprehensive systems management tools help increase uptime, reduce costs and improve productivity with advanced server management capabilities
- Support or two GPUs, high-IOPS SSDs and 10 GbE for different types of workloads
|
| |
HARDWARE SUMMARY:
- 2U rack server provides expandability and high performance in a dense form factor
- Up to two Intel Xeon Processor E5-2600 product family
- Up to 768 GB memory and up to 2 DIMMs per channel at 1600 MHz memory speed
- Integrated quad-port Gigabit Ethernet and optional embedded dual-port 10 GbE
- Up to 6 PCIe 3.0 expansion slots; Up to 4 optional PCI-X slot is available
- Up to 16 TB of 1.8-inch hot-swap SSDs or 16 TB of 2.5-inch hot-swap SAS/SATA/SSDs or 18 TB of 3.5-inch hot-swap or simple-swap SAS/SATA HDDs
- Embedded 6 Gbps hardware RAID-0, -1, -10. and optional RAID-5, -50 or -6, -60
- Hot-swap disk/fan/power supply, two fan zones with N+1 fans design, light path diagnostics and Predictive Failure Analysis, better thermal design, balanced efficiency, uptime and serviceability
|
| |
 |
| From Factor/Height |
Rack / 2U |
| Processor (Max) |
Up to two 8-core Intel Xeon E5-2600 series process |
| No. of Sockets |
2 |
| Cache (max) |
20 MB per processor |
| Memory (std/max) |
Up to 768 GB via 24 slots (UDIMM/RDIMM/LRDIMM/HyperCloud DIMM) |
| Media bays |
One optional ODD and tape drive bay |
| PCIe 3.0 Expansion Slots (x16/x8) |
4 - 6 PCIe ports or 4 PCI-X (CTO) or 2 double-width PCIe (for GPU) |
| Disk Bays |
Sixteen 2.5" or six 3.5" HDDs or thirty-two 1.8" SSDs
|
Maximun internal storage |
Up to 16 TB (2.5" model) or 18 TB (3.5" model) SAS/SATA |
| Network interface Controller(NIC) Trusted Platform Module(TPM) |
4 × 1 GbE (std.), 2 × 10 GbE Embedded Adapter (slotless opt.)/TPM |
| Power Supply(std/max) |
1/2 redundant 550 W ac, 750 W ac, 900 W ac, or 750 W dc (model dependent) |
| Hot-swap components |
Power supplies, fan modules and hard disk drives |
| USB Ports |
2 front/4 back/2 internal |
| VGA ports |
1 front/1 back |
| Energy Efficienty Compliance |
Compliant with 80 PLUS® Platinum and ENERGY STAR® (model dependent) |
| RAID support |
IBM ServeRAID M5110e RAID on motherboard,
integrated 6 Gbps hardware RAID-0, -1, -10, and optional RAID-5, -50 or -6, -60 |
| System Management |
IBM IMM2 with optional FoD remote presence, Predictive Failure Analysis, Diagnostic LEDs, light path diagnostics panel, Automatic Server Restart, IBM Systems Director and Active Energy Manager™ |
| Operating Sysytem Support |
Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware vSphere |
| Limited Warranty |
3 years |
|
|
|
 |
 |
|
