"Great multi-blade performance and 10Gb Fiber connectivity options"


With an ever-increasing number of evolving threats, today’s security gateway needs to be more than just a firewall—it must use multiple technologies to control network access, detect and mitigate sophisticated attacks, and provide additional security capabilities such as data loss prevention and protection from Web-based threats.The Check Point 4800 Appliances combine fast networking technology with high-performance multi-core capabilities—delivering exceptional multi-layered security protection without compromising on performance. With the Check Point 4800 Appliances and the extensible Software Blade Architecture, customers can be confident that the security solutions deployed will meet their protection needs and also match the performance requirements of the most demanding network environments.

HIGHLGHTS:

  • The 4800 Appliances pack a maximum of  161 Gigabit Ethernet ports,redundant hot-swappable power supplies
  • An optional out-of-band LOM  module into a compact 1U rack mountable form-factor
  • Supporting up to 11 Gbps of firewall throughput, 6 Gbps of IPS throughput and 623 Security Power Units

KEY FEATURES:

  • 623 SecurityPower™
  • 11 Gbps of firewall throughput
  • 6 Gbps of IPS throughput
  • Up to 16 10/100/1000Base-T ports
  • Up to 4 1GbE or 2 10GbE Fiber ports
  • Optional Lights-Out-Management (LOM)

BENEFITS:

  • Superior performance for its class
  • Compact 1U chassis for  integrated security and security consolidation
  • Reliable enterprise-class security appliance with multi coretechnology and remote management features
  • Flexible network options with copper, fiber, 1GbE and 10GbE ports
  • Proven and extensible security securing the perimeter and segments of enterprise networks
  • Simple deployment and centralized management from anywhere in the network
  • Remote management with Lights-Out-Management(LOM, 4800 only)





Performance

Enterprise Grade

Security Power

Up to 623

Firewall throughput (Gbps)

Up to 11

VPN Throughput (Gbps)

Up to 2

IPS Default (Gbps)

Up to 6

IPS Recommended Profile (Gbps)

Up to 1.5

Connections per second (K)

Up to 70

Concurrent  Sessions (M)

3.3 (With memory upgrade  and the GAiA OS)

Network Connectivity

10/100/1000 Base-T/Max Port

8/16

1000 Base-F SFP (Max ports)

4

10 GBase-F +(Max Port)

2

40GBase-F(MAX Port)

NA

Expansion

1

FONIC Option

YES
Additional Features

Software Edition

R 71.x, R 75.x

Storage 250 GB

Memory/ max

4/8 GB

LOM card

Included

Virtual Sysytem

Virtual system support

Yes

Number of Vs supported (max)

25

Memory/ max

63.1W
Physical Dimensions

Enclosure

1U

Standard (WxDxH)

17.25 x 16.14 x 1.73 in

Metric (WxDxH)

438 x 410 x 44 m

weight

7.6 kg
Power Requirements

Dual, HOT-swappable  power supplies

Optional

Power Input

100-240 VAC, 47-63 Hz

Single Power Supply Rating

275 W

Power Consumption  (MAX)

104 W

Maximum thermal Output

425.6 BTU

Operating Environmental Conditions

Temperature

32° to 104°F / 0° to 40°C

Humidity

20% to 90% (non-condensing)
