* POWER-1 APPLIANCE SPECIFICATIONS   Power-1 5070 Power-1 9070 Software edition NGX R65 Power NGX R65 Power Firewall throughput 9.0 Gbps 14.0 Gbps VPN throughput 2.4 Gbps 3.7 Gbps Concurrent sessions 1.1 Million 1.1 Million Users supported Unlimited Unlimited VLANs 256 256 Intrusion Prevention 4.5 Gbps 6.1 Gbps Storage capacity 160 GB 2x 160 GB Physical Specifications   Enclosure 2U 2U Dimensions(standard) 17x20X3.46 in 17x20X3.46 in Dimensions(metric) 431x509.5x88mm 431x509.5x88mm Weight 14.5kg 31.9 Ibs 16.5kg 36.3 Ibs GbE(10/100/1000) interfaces 8 + 4 optional 12 + 4 optional 10 GbE interfaces 2 optional 4 optional NIC options 4x1 GbE copper, SR fiber (single mode) 2x10 GbE SR/LR fiber (single mode) 4x1 GbE copper, SR fiber (single mode) 2x10 GbE SR/LR fiber (single mode) Management/Sync ports 2 2 Dual,hot-swappable power supplies Yes Yes Removable hard drives 1 2(hot swappable) Operating environment range Temperature:5˚ to 40˚ C, Humidity: 10%-85% non-condensing, Altitude:2,500m Power input 100~ 240V; 50~60Hz 100~ 240V; 50~60Hz Power consumption 250W (max.) 400W (max.) Compliance UL 60950; FCC Part 15, Subpart B, Class A; EN 55024; EN55022; VCCI V-3AS/NZS 3548:1995; CNS 13438 Class A (test passed; country approval pending); KN22KN61000-4 Series, TTA; IC-950; ROHS - Notes: Intusion prevention throughput is tesred using a blend of traffic similar to that seen on lntermet routers Spare parts, lights-out management, and NIC modules(line cards) available All Power-1 models come with a 3-year hardware warranty   * Power-1 Appliances(Security for high-performance environments)   Check Point Power-1™ appliances enable enable organizations to maximize security in high-performance environments such as large campuses or data centers. They combine firewall, IPSec VPN, and intrusion Prevention with advanced. acceleration technologies, delivering a high-performance security platform for multi-Gbps environments.   Industry-leading firewall VPN/firewall protection secures hunndreds of applications and protocols including VoIP, instant messaging (IM), and Peer-to-Peer(P2P) applications VPN (slte-to-slte, remote access) Feature-rich, easy-to-configure IPSec and SSL VPNs* Centrallzed, multlslte management Streamlines policy management for all sites via single console Intruslon prevention system (IPS) Advanced IPS with both signature-and protocol-anomaly-based detection High avallability, load balancing, and dynamic routing Reliability for critical applications and sites Web application Security* Protection against WEB attacks such as buffer overflow, SQL injection and cross-site scrioting web fiitering* Best-of-breed Web filtering protects against threats such as spyware, viruses, and inappropriate Web content Messaging security, Including email security and anti-spam* Protection against the three major messaging attack vestors:spam, malware delivered in messages, and attacks against the messaging infrastructure       * Available as an optional license     Power-1 5075 Power-1 9075 Power-1 11000 series 11065 11075 11085 Software Edition R65, R70 R65, R70 R70 R70 R70 10/100/1000 Port 10/14 14/18 14/18 14/18 14/18 Firewall Throughput² 9 Gbps 16 Gbps 15 Gbps 20 Gbps 25 Gbps VPN Throughput² 2.4 Gbps 3.7 Gbps 3.7 Gbps 4 Gbps 4.5 Gbps Concurrent Sessions 1.2 million 1.2 million 1.2 million 1.2 million 1.2 million IPS Throughput² 7.5 Gbps³ 10 Gbps³ 10 Gbps³ 12 Gbps³ 15 Gbps³ Licensed Users Unlimited Unlimited Unlimited Unlimited Unlimited VLANs 1024⁴ 1024⁴ 1024⁴ 1024⁴ 1024⁴ UTM Out of the Box Optional Optional Optional Optional Optional Security Acceleration Yes Yes Yes Yes Yes Integrated Multigateway Management - - - - - Storage 160 GB 2x 160 GB 2x 250 GB 2x 250 GB 2x 250 GB Enclosure 2U 2U 2U 2U 2U Dimensions (standard) 17X20 3.46 in 17X20 3.46 in 17X22.8 3.46 in 17X22.8 3.46 in 17X22.8 3.46 in Dimensions(metric) 431X509.5 88mm 431X509.5 88mm 431X580 88mm 431X580 88mm 431X580 88mm Weight 14.5kg (31.9 Ibs) 16.5kg (36.3 Ibs) 23.4kg (51.6 Ibs) 23.4kg (51.6 Ibs) 23.4kg (51.6 Ibs) Operating Environment Temperature:5˚ to 40˚ C, Humidity: 10%-85% non-condensing Power Input 100/240V, 50/60Hz Pwer Supply Spec(Max) 250 W 400W 500W 500W 500W       * Power-1 security specifications     Protection Details Firewall   Protocol/application support Secures more than 200 applications and protocols VoIP protection SIP, H.323, MGCP, and SIP with NAT support Instant Messaging control MSN, Yahoo, ICQ, and skype(including over HTTP and SSL) Peer-to-peer blocking Kazaa, Gnutella, BitTorrent, eMule, IRC(including over HTTP) Network Address Translation Static/hide NAT support with manual or automatic rules IPSec VPN   Encryption support AES 128-256 bit, 3DES 56-168 bit Authentication methods Password, RADIUS, TACACS, X.509, SecurID Certificate authority INtegrated X.509 certificate authority VPN communities Automatically sets up site-to-site connections when objects are created Topology support Star and mesh Route-based VPN Utilizes virtual tunnel interfaces, numbered/unnumbered interfaces VPN agent Check Point Endpoint Security™,VPN-1 SecureClient™, VPN-1 SecuRenote® SSL VPN   SSL-based remote access Fully integrated SSL gateway provides on-demand SSL-based remote access SSL-based endpoint scanning Scans endpoint for compliance/malware are prior to admission to the network Intrusion Prevention Blocks attacks such as Dos, port scanning, IP/ICMP/TCP-related Network-layer Protection Blocks attacks such as DNS cache poisoning, FTP bounce, improper commands, and more Detection methods Signature- and protocol-anomaly based Networking   Dynamic routing support OSPF, BGP, RIP v1 and 2, Multicast: PIM-SM, PIM-DM, DVMRP DHCP support SecurePlatform™ DHCP server and relay ISP redundancy Protocol-based, source/destination,and port route decisions Performance and availability   High availability Active/passive and active/active Load balancing integrated ClusterXL® smart load balancing Quality of Service FloodGate-1® for granular Qos ISP redundancy Automatically reroutes traffic to second interface Traffic acceleration SecureXL™ accelerates security decisions Multi-core acceleration CoreXL™ balances security decisions across multiple cores
